1W Battery Pack Thermal Conductive Potting Sealant Adhesive - Safe Heat Management

You are here: Home » Products » 2K Thermal Potting Compound » 2K Silicone Thermal Potting Compound » 1W Battery Pack Thermal Conductive Potting Sealant Adhesive - Safe Heat Management

2K Silicone Thermal Potting Compound- Ensures Heat Transfer, Insulation& Waterproof Sealing for Electronic Parts

3W LED Driver Potting Gel: Cools 3X Better

1W Battery Pack Thermal Conductive Potting Sealant Adhesive - Safe Heat Management

Color: white+black
Material: Organic silicon, Ceramic
Mixing Ratio: 1: 1 by weight
Application: Electrical Insulation, Fire Barrier, Thermal Insulation
Packing: 1kg/5kg/10kg/20kg drum

Quantity:
Availability:





Inquire Add to Basket

Model:
PS-10

Product Description

Company Introduction

FAQ

PS Heat-conducting Potting Compound is a kind of low viscosity flame retardant two component addition type silicone thermal conductive potting adhesive, which can be cured at room temperature or by heating, and has the characteristics that the higher the temperature is, the faster the curing speed is. The product does not produce any byproducts in the curing reaction, and can be applied to the surfaces of PC (poly-carbonate), PP, ABS, PVC and other materials and metals.It is suitable for heat conduction, insulation, waterproof, sealing and flame retardant of electronic accessories.

potting 12(1)

Product features

. Two-component, 1:1 mix for full and deep curing.

. High temperature resistance, low shrinkage and low expansion rate.

. Thermal conductivity, insulation, good dielectric properties.

. Resistant to vibration, moisture, corrosion, and the environment

. Prevent mechanical damage and have repairable function.

A silicone rubber potting compound is used to insulate or conceal electrical circuitry in professional and industrial applications.

Good fluidity and easy to pot;
Curable at room temperature or by heating;
UL94-V0 flame retardant grade;
100% solid, no curing byproducts;
Working temperature -50ºC~200ºC;
Fully compliant with ROHS directive requirements.

potting thermal 511

Thermal Interface Material can be used in 36 electronics industry, here are some application examples.
1. LED lighting, LED TV
2. Backlight module, switching power supply
3. Medical equipment, communication equipment
4. Mobile device, 5G network products
5. Video equipment, home appliances
6. PC server/workstation, base station

application 2(1) - 副本

Technical Data Sheet

Test Item	Unit	PS-10	PS-15	PS-20	PS-30	Test method
Composition	/	Organic silicon + ceramic
Color/Component A	/	White	White	White	White	Visual
Color/Component B	/	Grey	Grey	Grey	Grey	Visual
Viscosity/Component A	/	2000±500	4000±500	3500±1000	12000±2000	GB/T2794
Viscosity/Component B	/	2000±500	3000±500	3500±1000	12000±2000	GB/T1995
Mixing ratio	/	1:1	1:1	1:1	1:1
Density	G/cc	1.7±0.1	2.5±0.1	2.8±0.1	3.1±0.1	ASTM D792
Operating Time	Min	30	30	30	30	GB/T7123.1-2015
Hardness after curing Shore A	/	55±5	45±5	35±5	35±5	ASTM D2240
Temperature resistance range	ºC	-50~200	-50~200	-50~200	-50~200	-
Breakdown voltage	Kv/mm	≥12	≥12	≥12	≥12	ASTM D149
Volume resistivity	Ω.cm	≥1*10^13	≥1*10^13	≥1*10^13	≥1*10^13	ASTM D257
Dielectric constant	@ 10MHz	≥5	≥5	≥7	≥7	ASTM D150
Fire rating	/	V-0	V-0	V-0	V-0	UL94
Thermal conductivity	W/m-k	1.0±0.1	1.5±0.1	2±0.2	3±0.3	ASTM D5470

ShenZhen DuBang Technology Co., Ltd., our company's main products are thermal conductive silicone sheets, thermal conductive grease, thermal conductive potting glue, thermal conductive gel, thermal conductive insulation sheets, thermal conductive double-sided tape, thermal conductive graphite sheets and other products, which are widely used in automotive electronics, power supplies, LED lighting, network communications, smart devices, and household appliances.

10000 square meters original production base in DongGuan city
20 sets production process and 4 fully automatic production line to help quick lead time
With 100+ manufacturing raw material from oversea country
We have ROHS, UL, ISO 9001, ISO 14001, IATF 16949 certificate.
